Yuken EHDFG Series High Response Directional & Flow Control Valves
Description:
The Yuken EHDFG Series High Response Directional and Flow Control Valve is designed for hydraulic systems requiring fast response, precise flow regulation, and stable directional control. By combining high-performance solenoid actuation with advanced hydraulic design, the EHDFG series delivers accurate motion control and improved system efficiency.
share:
Yuken EHDFG Series High Response Directional & Flow Control Valves
Product Series
EHDFG Series – High Response Directional & Flow Control Valves
Valve Type
Electro-hydraulic proportional directional and flow control valve
Control Method
High-response solenoid with integrated electronic control
Mounting Standard
ISO 4401 / CETOP mounting interface
Rated Pressure
Up to 31.5 MPa (315 bar)
Rated Flow
Up to 160 L/min (model dependent)
Response Time
High dynamic response suitable for precision motion control
Flow Control Accuracy
Excellent repeatability and linearity
Working Fluid
Mineral hydraulic oil (ISO VG 32–68 recommended)
Operating Temperature Range
–20°C to +70°C
Electrical Specification
-
Rated Voltage: 24V DC (standard)
-
Connector: DIN standard
-
Protection Class: IP65 (with proper connector)
Applications
-
Injection molding machines
-
Die casting machines
-
Machine tools
-
Press systems
-
Automated hydraulic systems
