Yuken EHFBG Series Proportional Flow Control & Relief Valves

Yuken EHFBG Series Proportional Flow Control & Relief Valves

Product Name
Proportional Flow Control & Relief Valve

Series
EHFBG Series

Manufacturer
Yuken (Compatible / Replacement supplied by YsHydraulic)

Valve Type
Electro-hydraulic Proportional Flow Control & Relief Valve

Control Method
Proportional solenoid control (current or voltage input)

Mounting Type
Subplate mounting
ISO 4401 / CETOP standard

Nominal Size
NG06 (D03)
NG10 (D05)

Rated Flow
Up to 40 L/min (NG06)
Up to 100 L/min (NG10)

Maximum Operating Pressure
Up to 31.5 MPa (315 bar)

Pressure Adjustment Range
Depending on model (refer to specific code)

Electrical Specifications
Rated voltage: 24 V DC
Current control recommended
Connector: Standard DIN type

Response Characteristics
High response speed
Stable pressure and flow control

Hydraulic Fluid
Mineral hydraulic oil (ISO VG 32–68)

Operating Temperature Range
–10 °C to +60 °C

Application Areas
• Machine tools
• Injection molding machines
• Hydraulic presses
• Industrial automation systems
• Energy-saving hydraulic circuits
