Bosch Rexroth M-3SED6UK1X Poppet Directional Valve
Description:
The Bosch Rexroth M-3SED6UK1X Poppet Directional Valve is a direct-operated, solenoid-actuated seat valve designed for reliable on/off hydraulic flow control. Featuring a poppet (seat) design, it provides virtually zero internal leakage, making it ideal for applications requiring secure load holding and precise directional control. The valve is commonly used in industrial hydraulic systems, machine tools, presses, automation equipment, and mobile machinery. It supports subplate mounting according to ISO 4401 and offers excellent durability under high-pressure operating conditions.
share:
Bosch Rexroth M-3SED6UK1X Poppet Directional Valve
| Parameter | Specification |
|---|---|
| Product Name | Bosch Rexroth M-3SED6UK1X Poppet Directional Valve |
| Valve Type | Direct-operated poppet directional valve |
| Valve Design | Seat (Poppet) Valve |
| Size | NG6 / Size 6 |
| Mounting | Subplate mounting |
| Mounting Standard | ISO 4401-03-02-0-05 |
| Switching Positions | 3/2 (Symbol UK) |
| Actuation | Wet-pin solenoid |
| Operating Pressure | Up to 350 bar |
| Maximum Flow Rate | 25 L/min |
| Supply Voltage | 24 V DC (common version) |
| Electrical Connector | 3-pin connector (2 + PE) |
| Electrical Standard | EN 175301-803 |
| Hydraulic Fluids | HL, HLP, HLPD, HVLP, HVLPD, HFC |
| Internal Leakage | Virtually zero (seat valve design) |
| Seal Material | NBR |
| Weight | Approx. 1.42 kg |
| Typical Applications | Hydraulic power units, machine tools, presses, automation systems, industrial machinery |
