Denison PD Series Hydraulic Pump
Description:
The Denison PD Series Hydraulic Pump is a high-performance axial piston pump designed for demanding industrial and mobile hydraulic applications. Known for its robust construction, high-pressure capability, and long service life, the PD Series delivers efficient hydraulic power with precise flow control. These pumps are widely used in manufacturing equipment, metal processing machinery, injection molding systems, marine equipment, and heavy-duty industrial hydraulic systems.
share:
Denison PD Series Hydraulic Pump
| Parameter | Specification |
|---|---|
| Product Type | Axial Piston Hydraulic Pump |
| Series | PD Series |
| Manufacturer | Denison Hydraulics / Parker Hannifin |
| Mounting Type | SAE Mounting Flange |
| Pump Design | Variable Displacement Axial Piston |
| Rotation | Clockwise / Counterclockwise |
| Displacement Range | 18 cc/rev – 260 cc/rev (depending on model) |
| Maximum Operating Pressure | Up to 350 bar (5075 psi) |
| Peak Pressure | Up to 420 bar (6090 psi) |
| Speed Range | 600 – 3000 rpm |
| Fluid Type | Mineral Oil Hydraulic Fluids |
| Viscosity Range | 10 – 400 cSt |
| Operating Temperature | -20°C to +80°C |
| Control Options | Pressure Compensation, Load Sensing, Remote Control |
| Efficiency | Up to 95% Volumetric Efficiency |
| Housing Material | High-Strength Cast Iron |
| Application | Industrial & Mobile Hydraulic Systems |
