Parker MGV Motor
Description:
The MGV Motor is a hydraulic motor designed to convert hydraulic energy into mechanical rotary power for a wide range of hydraulic drive applications. Its compact construction and reliable operating characteristics make it suitable for industrial machinery, mobile equipment and other hydraulic systems requiring stable rotary motion. The exact displacement, pressure, speed, torque and mounting specifications depend on the selected MGV model. YsHydraulic supplies hydraulic motors and other branded hydraulic components with technical support, competitive pricing and reliable after sales service.
share:
Parker MGV Motor
Product Name: Parker MGV Motor
Product Series: MGV Series
Product Type: High Speed Motor
Motor Type: Permanent Magnet Synchronous Motor
Magnet Material: Nd Fe B
Cooling Method: Water Cooled
Mounting: B3 Foot Mounting or B5 Flange Mounting
Protection Degree: IP40 Standard
Rated Voltage: 400 VAC or 480 VAC
Feedback Sensor: Resolver
Optional Feedback: Sin Cos Encoder
Thermal Protection: PTC Probe and KTY84 130 Sensor
Bearing Options: Steel or Ceramic Bearings Depending on Speed and Load
Operating Temperature: 0 to 40 C
Cooling Water Temperature: 5 to 25 C
Insulation Class: Class F
Application: High Speed Test Rigs and Industrial Test Systems
Maximum Speed: Up to 45000 rpm depending on model
Power Range: Model dependent, with configurations up to approximately 80 kW
Shaft: Smooth Shaft Standard
